Scope of application of grain dryer:
It is suitable for drying corn, wheat, rice and other food crops. The drying quality of wheat and corn is good, and the drying rate of rice is low, broken rice is less, and the color is white, which is the most prominent advantage of this machine. It can be widely used in rural areas, small farms and medium and small feed mills.
PARAMETER
| Model | HL-LSHG30 | HL-LSHG60 | HL-LSHG120 | HL-LSHG150 | HL-LSHG200 | HL-LSHG300 |
| Capacity (tons/day) | 30 | 50 | 120 | 150 | 200 | 300 |
| Dimensions (m) | 2.5×2.5×11 | 3.0×3.0×12 | 2.5×2.5×18 | 2.5×2.5×19 | 3.0×3.0×20 | 3.0×3.0×22 |
| Processing (/h) | 1.5 | 2.5 | 5 | 7.5 | 10 | 13 |
| drying cycle | 3h | |||||
| Precipitation amplitude (%) | 8-16 | |||||
| Finished dryness (%) | 14.5-15.5 | |||||
| heating medium | clean hot air | |||||
| Hot air temperature (℃) | ＜120 | |||||
| Maximum heating temperature of grain (℃) | 55-60 | |||||
| Drying unevenness (%) | ＜2 | |||||
| Breaking rate increase (%) | ＜0.5 | |||||
| Unit heat consumption (kj/kgH2O) | 5800 kJ | |||||
| Coal consumption (kg/h) | 20-30 | 38-40 | ≈ 45 | ≈ 50 | ≈ 55 | ≈ 60 |
| Installed capacity (T) | 26 | 36 | 40 | 50 | 60 | 70 |
| Installed power (kw) | 16 | 22 | 65 | 80 | 110 | 130 |
